Image is for your reference only, please check specifications for details
iconCompare
icon

3020-01096-0

  • Available: 499

Reference Price(In US Dollars)

QtyUnit PriceExt.Price
1+US $39.10240US $39.10
10+US $29.32680US $293.27
30+US $25.41656US $762.50
100+US $22.48388US $2248.39
500+US $21.11530US $10557.65
1000+US $19.55120US $19551.20

Do you want a lower wholesale price? Please send us an inquiry, and we will respond immediately.

Quick RFQ
  • esd
  • as
  • iso14001
  • iso9001
  • D&B

Product Parameter

  • Manufacturer
    Murata Power Solutions
  • Manufacturer's Part No.
    3020-01096-0
  • Categories
    Resistors
  • Sub-Categories
    Chassis Mount Resistors
  • Series
    DMS
  • ECCN
    EAR99
  • Width
    31.7mm
  • Height
    42.7mm
  • Length
    50.8mm
  • Feature
    Current Sense
  • Accuracy
    0.25 %
  • Packaging
    Bulk
  • Tolerance
    ±0.25%
  • Resistance
    1mOhms
  • Composition
    Metal Element
  • Part Status
    Active
  • Termination
    Wire
  • Power Rating
    5W
  • REACH Status
    REACH Unaffected
  • Input Current
    50A
  • Power (Watts)
    2.5W
  • Current Rating
    50A
  • Output Voltage
    50mV
  • Package / Case
    Rectangular Case
  • Mounting Feature
    Flanges
  • Size / Dimension
    2.000Lx1.248W 50.80mmx31.70mm
  • Factory Lead Time
    12 Weeks
  • Height Seated (Max)
    1.680 42.70mm
  • Max Power Dissipation
    2.5W
  • Operating Temperature
    -40°C~60°C
  • Nominal Supply Current
    50A
  • Temperature Coefficient
    ±15ppm/°C
  • Max Operating Temperature
    60°C
  • Min Operating Temperature
    -40°C

Environmental & Export Classifications

  • HTSUS
    8533.21.0090
  • REACH SVHC
    No SVHC
  • RoHS Status
    ROHS3 Compliant
  • Moisture Sensitivity Level (MSL)
    Not Applicable
